BAITU | BAITU 51.2v 100ah lithium ion battery 48V 100Ah 5kw 6kw 10kw solar systems 48v 100ah lifepo4 battery pack

Guangzhou Baitu New Energy Battery Material
Technology Co. , Ltd.

Custom manufacturer

Custom manufacturer
For buyers looking for products with high customization and specialization, Custom Manufacturers provide dedicated production lines and custom design capabilities with an emphasis on meeting quality, delivery, and after-sales service requirements.

15 Years  ·  GUANGZHOU , China

Main categories:Lifepo4 Battery / Lithium Battery / Solar Inverter / Solar Panel / Industrial and commercial energy storage / energy storage system / home energy storage / Hydrogen fuel battery / Hydrogen production / hydrogen energy storage systems

  • OEM
  • ODM
  • Agent distribution
Chat now

BAITU 51.2v 100ah lithium ion battery 48V 100Ah 5kw 6kw 10kw solar systems 48v 100ah lifepo4 battery pack

Other attributes

Battery Type

LiFePO4

Output Power Range

10~20 kWh

System Type

Rack-mounted

Model Number

51.2V100AH

Brand Name

TAICO

Place of Origin

China

Type

Split

Communication Port

CAN, RS232, RS485

Protection Class

IP54

Grid connection

Off grid

Features

Deep Cycle Long Life

Battery type

Lifepo4 Battery

Warranty

3Year, enable to prolong

OEM/ODM

Welcomed

Casing

Iron / Custom

Application1

SUBMARINES

Application2

Solar Energy Storage Systems

Application3

Uninterruptible Power Supplies

Packaging and delivery

Selling Units:

Single item

Single package size:

60X40X5 cm

Single gross weight:
50.000 kg
More>>
Clear
Add to quote
Description

Product Description



Specification

Nominal Voltage
51.2V
Norminal Capacity
100Ah 200Ah 300Ah
Dimensions (mm)
4U 480x438x177mm
Internal Resistance
≤30mΩ
Months Self Discharge
<3%
Cycle Life
>6000
Charging Voltage
58.4±1Vdc
Charge Mode
0.2C to 58.4V, then 58.4V,charge current to 0.02C (CC/CV)
Recommended Charger Curren
≤50A
Allowed Max. Charge Current
100A
Charge Cut-off Voltage
57.6±1Vdc
Continuous Discharge Current
100A （1C）
Charge Temperature
0’C to 45’C (32°F to 113°F)
Discharge Temperature
-20° C to 60°C(4°F to140°F)
Enclosure Protection Level
IP54
Working Environment
0℃ to 40℃ (32℉ to 104℉)
Cell&Capacity
50AH
Cell type
Solid lithium battery cell
Shell material
Iron Rack Mount Case
Additional Information
Color

White
Capacity

50Ah, 100Ah, 150Ah, 200Ah, 300Ah
apacitySystem Voltage:

51.2 V
